Downlight / CDP3

PRODUCT & POWER OPTIONS

Product Name	Light Color	Input Voltage (V)	Power (W)	Luminous Flux (lm)	Bore Diameter (C) (mm)	Product Weight (kg)
CDP3 09	WW-NW-CW	220-240V AC	12	1.225	Ø170	1,4
CDP3 09	WW-NW-CW	220-240V AC	17	1.685	Ø170	1,4
CDP3 09	WW-NW-CW	220-240V AC	23	2.395	Ø170	1,6
CDP3 09	WW-NW-CW	12-24V DC	11	1.120	Ø170	1,2
CDP3 09	WW-NW-CW	12-24V DC	15	1.580	Ø170	1,2
CDP3 09	WW-NW-CW	12-24V DC	22	2.290	Ø170	1,2

*Power and Lumen values provided are based off of a “cold white (CW) LED”.

ELECTROMECHANICAL SPECIFICATIONS

• Electrostatic powder coated aluminum injection housing and DKP front frame
• Polycarbonate front glass
• Stainless connectors
• Suitable for recessed mounting
• Anti-glare reflector (RAL9005)

LIGHT COLOR OPTIONS

	WW:Warm White	3000K
	NW:Natural White	4000K
	CW:Cold White	6500K

S
DRIVER OPTIONS
- 01: Standart (ON/OFF)
- 06: DALI Driver
- 11: Driver + Emergency Lighting Kit 1h
- 12: Driver + Emergency Lighting Kit 3h
O
LENS OPTIONS
- XN: Extra Narrow Angle
- M: Medium Angle
- W: Wide Angle
- XW: Without Lens
G
HOUSING COLOR OPTIONS
- RAL9005
- RAL9016
- RAL9007
I
IP PROTECTION CLASS
M
MOUNTING OPTIONS
- 09: Fixed
- 10: Fixed Deep*
- 11: Deep movable*
- 12: Deep recessed movable*
*IP65 is not available
