  • P

    PRODUCT & POWER OPTIONS

    Product Name Light Color Input Voltage (V) Power (W/mt) Luminous Flux (lm) Product Weight (kg)
    LLW2 30LED WW-NW-CW 24V DC 12 490 1,6
    LLW2 45LED WW-NW-CW 24V DC 18 710 1,6
    LLW2 60LED WW-NW-CW 24V DC 14,4 730 1,6
    LLW2 60LED WW-NW-CW 24V DC 24 940 1,6
    LLW2 90LED WW-NW-CW 24V DC 7,2 315 1,6
    LLW2 90LED WW-NW-CW 24V DC 36 1350 1,6
    LLW2 180LED WW-NW-CW 24V DC 14,4 625 1,6
    LLW2 30LED RGB 24V DC 7,2 - 1,6
    LLW2 45LED RGB 24V DC 10,8 - 1,6
    LLW2 60LED RGB 24V DC 14,4 - 1,6
    LLW2 90LED RGB 24V DC 21,6 - 1,6
    LLW2 60LED RGB/W 24V DC 14,4 - 1,6
    LLW2 30LED-DMX RGB-Pixel 24V DC 804 - 1,6
    LLW2 45LED-DMX RGB-Pixel 24V DC 12,6 - 1,6
    LLW2 30LED-DMX RGBW/A-Pixel 24V DC 8,4 - 1,6

    *Power and Lumen values provided are based off of a “cold white (CW) LED”.

    ELECTROMECHANICAL SPECIFICATIONS

    • Min. 20 micron anodized aluminum extruded profile
    • Stainless connectors
    • PVC side cover with UV protection
    • Diffused polycarbonate front cover with UV protection
    • Cooling capacity up to 36W/m
    • Suitable Surface mount

  • C

    LIGHT COLOR OPTIONS

    WW:Warm White 3000K R:Red 625nm RGB
    NW:Natural White 4000K G:Green 525nm RGBW
    CW:Cold White 6500K B:Blue 465nm RGBA
    A:Amber 590nm
  • J

    CONNECTIONS OPTIONS

    • 01: Cable*
    • 02: IP Socket

    *IP66 products are socket only

  • U

    UPPER PIECE OPTIONS

    • 01: Diffused
      (IP40/IP66)
    • 02: Transparent
      (IP40/IP66)
  • I

    IP PROTECTION CLASS

  • M

    MOUNTING OPTIONS

    • 07: DT28
    • 08: DT48
  • CONTROL SYSTEM OPTIONS

    Color Type PWM INW PWM DMX DALI 0 - 10V DC TRIAC
    WW-NW-CW
    R,G,B,A
    RGB
    RGBA/W
    RGB DMX
    WHITE DMX
  •  PRODUCT DIAGRAMS
    LLW2 LLW2
  • a2.svg
  • a6.svg
  • a15.svg
  • c4.svg
  • c13.svg
  • c15.svg
  • c7.svg
  • c9.svg
  • c11.svg
  • b27.svg
  • b26.svg
