LEDLine / LLO

PRODUCT & POWER OPTIONS

Product Name	Light Color	Input Voltage (V)	Power (W)	Luminous Flux (lm)	Weight (kg)
LLO 60LED	WW-NW-CW	24V DC	7,2	390	0,28
LLO 60LED	WW-NW-CW	24V DC	14,4	775	0,28
LLO 90LED	WW-NW-CW	24V DC	10,8	620	0,28
LLO 120LED	WW-NW-CW	24V DC	9,6	570	0,28
LLO 180LED	WW-NW-CW	24V DC	14,4	930	0,28

*Power and Lumen values provided are based off of a “natural white (NW) LED”

ELECTROMECHANICAL SPECIFICATIONS

• Min. 20 micron anodized aluminum extruded proﬁle
• Stainless connectors
• PVC side cover with UV protection
• UV protected optical lens
• Suitable for surface mounting
• Narrow beam linear LED strip

C
LIGHT COLOR OPTIONS

WW:Warm White 3000K

NW:Natural White 4000K

CW:Cold White 6500K
O
LENS OPTIONS
- E: Elliptical
  Angled
J
CONNECTIONS OPTIONS
- 07 IP Socket (bottom output)
M
MOUNTING OPTIONS
- 01 Steel Clip
- 02 Double-Sided Tape
- 03 Aluminum Clip
- 04 Aluminum Clip (tall)
- 05 Angled Clip
