Road Lighting Luminaire / AYFER4

  • P
  • W
  • C
  • S
  • O
  • G
  • M
  • P

    PRODUCT & POWER OPTIONS

    Product Name Light Color Input Voltage (V) Power (W) Luminous Flux (lm) Weight (kg)
    AYFER4 WW-NW-CW 220-240V AC 30 3.930 2,6
    AYFER4 WW-NW-CW 220-240V AC 40 5.125 2,7
    AYFER4 WW-NW-CW 220-240V AC 50 6.150 2,9

    * Power and Lumen values provided are based off of a “cold white (CW) LED”.

    ELECTROMECHANICAL SPECIFICATIONS


    • Electrostatic powder coated, die-cast aluminum body and spigot
    • 5mm tempered glass
    • Ø60mm spigot adaptor can be fitted post-top or lateral entry +15°/-15° tilt angle
    • 6kV/10kV lighting protective circuit
    • ENEC certificated, 50.000h life time constant current driver

  • C

    LIGHT COLOR OPTIONS

    WW:Warm White 3000K
    NW:Natural White 4000K
    CW:Cold White 6500K
  • S

    DRIVER OPTIONS

    • 01: Standart Driver
    • 06: DALI Driver
  • O

    LENS OPTIONS

    • XW: Without Lens
    • ME3: 90x120
  • G

    HOUSING COLOR OPTIONS

    • RAL9005
    • RAL9007
    • RAL9016
  • CONTROL SYSTEM OPTIONS

    Color Type PWM INW PWM DMX DALI 0 - 10V DC TRIAC
    WW-NW-CW
    R,G,B,A
    RGB
    RGBA/W
    RGB DMX
    WHITE DMX
  • M

    MOUNTING OPTIONS

    • MK42 Ø42
    • MK60 Ø60
  •  PRODUCT DIAGRAMS
    AYFER4
  • a6.svg
  • a18.svg
  • a12.svg
  • c1.svg
  • c4.svg
  • c5.svg
  • c10.svg
  • c14.svg
  • b24.svg
  • b25.svg
  • b36.svg
  • b35.svg
