Pool Lighting / AC5N

  • P
  • W
  • C
  • S
  • O
  • B
  • K
  • U
  • P

    PRODUCT & POWER OPTIONS

    Product Name Light Color Input Voltage (V) Led Quantity (qty/m) Power (W) Luminous Flux (lm) Dimensions Product Weight (kg)
    AC5N18 WW-NW-CW 12-24V DC 18 21 2100 177x183 0,8-1,7
    AC5N18 WW-NW-CW 12-24V DC 18 32 3200 177x183 0,8-1,7
    AC5N18 WW-NW-CW 12-24V DC 18 46 4800 177x183 0,8-1,7
    AC5N18*** RGB 24V DC 18 26 - 177x183 0,8-1,7
    AC5N18*** RGB 24V DC 18 36 - 177x183 0,8-1,7

    *Power and Lumen values provided are based off of a lensless product with cold white (CW) LED. It may vary according to the desired colour.
    ** Product weight provided is based off of chrome and aluminum options.
    *** RGB products can be produced in 12-24 V DC and product values may vary.

    ELECTROMECHANICAL SPECIFICATIONS

    • Chrome coated or PC spot frame in white color
    • 316 L Press forming chrome body or aluminum injection electrostatic powder coated body
    • Polycarbonate glass
    • 316 L Stainless connecters
    • Operates with alternate or direct current
    • Underwater connector
    • H07RNF rubber cable

  • C

    LIGHT COLOR OPTIONS

    WW:Warm White 3000K R:Red 625nm
    NW:Natural White 4000K G:Green 525nm
    CW:Cold White 6500K B:Blue 465nm
    RGBA:Amber590nm
  • S

    SYSTEM OPTIONS

    • 01: Standart (ON/OFF)
    • 02: PWM-DIM
    • 03: InvertPWM-DIM
  • O

    LENS OPTIONS

    • XN: Extra Narrow Angle
    • M: Medium Angle
    • W: Wide Angle
    • XW: Without lens
  • B

    BODY OPTIONS

    • 09: Aluminum Body - IP67
    • 10:Chrome Body - IP68

    *Additional underwater cable joint has to be used in need of extra underwater cables.

  • K

    CABLE DIRECTION OPTIONS

    • 08: Single entryt through center
    • 09: Single bottom entry
    • 10: Entry and exit through cover

    *Additional underwater cable joint has to be used in need of extra underwater cables.

  • U

    UPPER PIECE OPTIONS

    • 15: Chrome plated spot mirror
    • 16: White plastic spot mirror
  • MOUNTING

    Stand Extension Piece

    • 34: 5cm 35: 10cm 36: 20cm
  • CONTROL SYSTEM OPTIONS

    Color Type PWM INW PWM DMX DALI 0 - 10V DC TRIAC
    WW-NW-CW
    R,G,B,A
    RGB
    RGBA/W
    RGB DMX
    WHITE DMX


    Product Code Voltage (V DC) Control Systems Cable Core Quantity
    Mono RGB RGB W/A
    AC5N18 24 PWM 2X 4x -
    12-24 ON/OFF 2x - -
    12-24 INV-PVM 3X 5X -
  •  PRODUCT DIAGRAMS
    AC5N AC5N
  • a40.svg
  • a7.svg
  • a19.svg
  • c3.svg
  • c15.svg
  • c13.svg
  • c4.svg
  • c5.svg
  • c11.svg
  • c17.svg
  • b39.svg
  • b37.svg
  • b38.svg
